Features and Applications
Aluminium wire designed to meet the tensile strength requirements of high magnesium alloys.
Excellent weldabillity and good mechanical strength, combined with good corrosion resistance in seawater conditions.
Ideal for applications demanding high fracture toughness and impact.
Not recommended for elevated temperature applications.
Thicker sections should be preheated to (150°C) prior to welding.
Typically used on applications in shipyards, automotive, railway, tanks and marine component fabrication etc.
Test Certificates can be found online @wilkinsonstar247.com
Typical Base Materials
AlMg4,5Mn, AlMg5, AlMg2Mn0,8, AlZnMg1, AlZnMgCu0,5, AlMgSi0,5, AlMgSi1, G-AlMg10, G-AlMg5, G-AlMg3Si, G-AlMg5Si, 3.3545, 3.3547, 3.3535, 3.3555, 3.3206, 3.3210, 3.2315, 3.3211, 3.4335, EN AW 5086, EN AW 5083, EN AW 5019, EN AW 5019, EN AW 6060, EN AW 6005A, EN AW 6082, EN AW 6061, EN AW 7020, EN AC 51300, EN AC 51400*
* Illustrative, not exhaustive list
| Standards |
EN ISO 18273 - S Al 5183 (AlMg4.5Mn0.7(A))
|
AWS A5.10 - ER 5183
|
| Chemical Composition % (Typical) |
| Si% |
Fe% |
Cu% |
Mn% |
Mg% |
|
|
| 0.0521 |
0.0800 |
0.0015 |
0.6280 |
4.8521 |
|
|
| |
|
|
|
|
|
|
| Cr% |
Zn% |
Ti% |
Be% |
Al% |
|
|
| 0.0979 |
0.0037 |
0.0816 |
<0.0001 |
Rem. |
|
|
Mechanical Properties
|
| Tensile Strength |
≥275 MPa |
|
| Yield Strength |
≥125 MPa
|
|
| Elongation |
≥17 %
|
|
| Impact Strength |
≥16 J
|
|
Mechanical properties are approximate and may vary based on the heat, shielding gas, welding parameters and other factors.
Shielding Gases
EN ISO 14175 - TIG: I1, I3
Welding Positions
EN ISO 6947 - PA, PB, PC, PD, PE, PF, PG
| Packaging Data |
Diameter
|
Length
|
Weight |
|
|
1.60 mm
2.40 mm
3.20 mm
|
1000 mm
1000 mm
1000 mm
|
2.5 Kg
2.5 Kg
2.5 Kg
|
|
Liability: Whilst all reasonable efforts have been made to ensure the accuracy of the information contained, this information is subject to change without notice and can be only considered as suitable for general guidance.
